| Place of Origin: | China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE, ISO9001:2008, SGS |
| Model Number: | OCM-280H |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 2 months |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 500 sets/year |
| Product Name: | High Precision 280T Plastic Basket Orange Professional Injection Molding Units Injection Molding Machine Making | Type: | Automation |
|---|---|---|---|
| Function: | Plastic Parts Production | Motor: | Servo Energy Saving |
| Color: | Support Customization | Stable Performance: | Short Cycle Time |
| Clamping Way: | Hydraulic | Transport Package: | FCL |
| High Light: | plastic injection molding machine High Precision,280T plastic injection molding machine,Orange high precision injection molding |
||
OUCO in the process of development, always do not forget the original intention, adhere to scientific and technological progress as a guide, continuous innovation and transformation of research, and vigorously independent research and development, the formation of its own characteristics of the core technology, high-speed machine HS series, standard machine H series and so on, to a certain extent, to meet the requirements of the high-end precision equipment for the injection molding, only to bring you a high-quality sense of use.
Product Advantages
OUCO280T injection molding machine is a small precision injection molding machine with compact and precise design, fitted with servo motor pump drive, energy saving more than 50% and ultra-low energy consumption. The precise computer controller not only controls each operation period with low noise, but also its stable and efficient hydraulic system reduces the time cost and injection cost for the production.
Parameters
| MODEL | OCH-280T | |||||
| Clamping force (kN) | 2800 | |||||
| Space between tie bar (mm*mm) | 610*590 | |||||
| Max. mold thickness (mm) | 620 | |||||
| Min. mold thickness(mm) | 220 | |||||
| Opening stroke (mm) | 570 | |||||
| Ejector stroke(mm) | 160 | |||||
| Ejector force forward(Kn) | 77 | |||||
| Screw diameter(mm) | 70 | |||||
| Screw L/D ratio | 20 | |||||
| Theoretical injection volume (cm3) | 1077 | |||||
| Shot weight (PS) g | 980 | |||||
| Injection pressure(MPa) | 130 | |||||
| Injection speed (mm/s) | 106 | |||||
| Injection rate (g/s) | 583 | |||||
| Motor power (Kw) | 36 | |||||
| Oil tank capacity(L) | 380 | |||||
| Heater power (Kw) | 18 | |||||
| Machine Weight (t) | 9 | |||||
| Machine size L×W×H (m) | 6.4*1.5*2.2 | |||||
