| Place of Origin: | China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE, ISO9001:2008, SGS |
| Model Number: | OCM-530T |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 2 months |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 500 sets/year |
| Product Name: | OUCO 530T High Quality High Output Plastic Fruit Box Yellow Crate Injection Molding Machine Hydraulic Servo | Type: | Automation |
|---|---|---|---|
| Function: | Plastic Parts Production | Motor: | Servo Energy Saving |
| Color: | Support Customization | Stable Performance: | Short Cycle Time |
| Clamping Way: | Hydraulic | Transport Package: | FCL |
| High Light: | 530T servo motor injection molding machine,Automation injection molding machine servo motor,530T injection molding machine servo motor |
||
OUCO injection moulding machine expands its unique performance by installing auxiliary injection device on the basis of adopting servo system. With strong market adaptability, our company can provide better injection moulding machine customization service to meet the diversified needs of customers. Our concept is to design, develop, produce and sell multifunctional specialised plastic machine equipment to build our own brand.
Product Advantages
Professional plasticising unit: the fruit baskets produced are reasonably matched with the plasticising unit according to the user's demand, which ensures the consistent and fine quality of the fruit baskets.
Professional melting unit: adopting good materials, barrels and screws, the melting speed is fast, the melting time is short, and it is not easy to leak the glue. High pressure and high speed operation is not easy to cause the precursor to crack its ensure the fruit baskets strong and durable, long service life.
Unique hydraulic system: oil circuit design, the use of cartridge valve plate, fast response time, accurate pressure and speed control, high moulding precision, the production of fruit baskets are not easy to deform, less scrap.
Parameters
| MODEL | OCM-530T | |||||
| Clamping force (kN) | 530 | |||||
| Space between tie bar (mm*mm) | 810*810 | |||||
| Max. mold thickness (mm) | 850 | |||||
| Min. mold thickness(mm) | 300 | |||||
| Opening stroke (mm) | 810 | |||||
| Ejector stroke(mm) | 250 | |||||
| Ejector force forward(Kn) | 150 | |||||
| Screw diameter(mm) | 90 | |||||
| Screw L/D ratio | 24 | |||||
| Theoretical injection volume (cm3) | 2700 | |||||
| Shot weight (PS) g | 3330 | |||||
| Injection pressure(MPa) | 149 | |||||
| Injection speed (mm/s) | 170 | |||||
| Injection rate (g/s) | 750 | |||||
| Motor power (Kw) | 55 | |||||
| Oil tank capacity(L) | 750 | |||||
| Heater power (Kw) | 34 | |||||
| Machine Weight (kg) | 23 | |||||
| Machine size L×W×H (mm) | 8400*2200*2700 | |||||
Detail Pictures
