| Place of Origin: | China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE, ISO9001:2008, SGS |
| Model Number: | OUCO-350T |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 2 months |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 500 sets/year |
| Product Name: | High Quality PET Preform Injection Molding Machine With Larger Power System | Type: | Automation |
|---|---|---|---|
| Function: | Plastic Parts Production | Motor: | Servo Energy Saving |
| Color: | Support Customization | Stable Performance: | Short Cycle Time |
| Clamping Way: | Hydraulic | Transport Package: | FCL |
| High Light: | 65mm PET Injection Molding Machine,350Ton PET Injection Molding Machine,SGS electric injection moulding machines |
||
Product Description
Safe and controllable, more at ease
Large color screen control panel, emergency stop switch protection, comprehensive monitoring of actions, real-time monitoring, safe and controllable
The control panel adopts a color screen to monitor the production process in real time and display various fault diagnosis, making the operation more worry-free
Humanized process parameter setting, setting emergency stop switch, comprehensive monitoring of actions, protecting the personal safety of staff
Product Parameters
| 技术參数 SPECIFICATION | ZP2000 | ZP2300 | ZP2800 | ZP3200 | ZP3800 | ZP4300 | ZP4800 | ZP5300 | ZP6200 | ||||||||||
| 注射部份 INJECTION UNIT | IU1100 | IU1100 | IU1700 | IU2400 | IU3000 | IU3600 | IU4400 | IU4400 | IU5700 | ||||||||||
| 注射容積 Shot Weight | cm3 | 829 | 829 | 1270 | 1885 | 2497 | 2799 | 3534 | 3534 | 4752 | |||||||||
| 注射量(PET) Injection Weight | g | 962 | 962 | 1473 | 2187 | 2897 | 3247 | 4099 | 4099 | 5512 | |||||||||
| 螺杆直徑 Screw Diameter | mm | 65 | 65 | 70 | 80 | 85 | 90 | 100 | 100 | 110 | |||||||||
| 螺杆長徑比 Screw L/D Ratio | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | ||||||||||
| 注射壓力 Injection Pressure | Mpa | 137 | 137 | 135 | 127 | 121 | 130 | 125 | 125 | 121 | |||||||||
| 注射速率 Injection Rate | cm3/s | 306 | 333 | 306 | 333 | 450 | 424 | 479 | 455 | 589 | 589 | 647 | 700 | 723 | 734 | 723 | 734 | 851 | 880 |
| 最大塑化能力(PET) Plasticzation Capacity | g/s | 57 | 62 | 57 | 62 | 69 | 85 | 68 | 65 | 96 | 96 | 107 | 116 | 128 | 130 | 128 | 130 | 143 | 148 |
| 最大螺杆轉速 Max Screw Speed | rpm | 162 | 176 | 162 | 176 | 192 | 181 | 162 | 154 | 138 | 138 | 133 | 144 | 120 | 122 | 120 | 122 | 114 | 118 |
| 合模部份 CLAMPING UNIT | |||||||||||||||||||
| 合模力 Clamping Force | Kn | 2000 | 2300 | 2800 | 3200 | 3800 | 4300 | 4800 | 5300 | 6200 | |||||||||
| 最大移模行程 Clamping Stroke | mm | 450 | 530 | 590 | 640 | 680 | 750 | 830 | 850 | 900 | |||||||||
| 連接柱内矩 Space Between Tie Bar (HxV) | mm | 510 X 460 | 560 X 510 | 620 X 570 | 670 X 620 | 730 X 680 | 770 X 720 | 820 X 800 | 860 X 810 | 910 X 860 | |||||||||
| 最大模板矩離 Max. Daylight | mm | 1130 | 1130 | 1240 | 1320 | 1410 | 1500 | 1630 | 1700 | 1800 | |||||||||
| 最大容模厚度 Max. Mold Height | mm | 560 | 600 | 650 | 680 | 730 | 750 | 800 | 850 | 900 | |||||||||
| 最小容模厚度 Min. Mold Height | mm | 160 | 180 | 220 | 250 | 280 | 280 | 320 | 320 | 350 | |||||||||
| 頂出行程 Ejector Stroke | mm | 140 | 150 | 180 | 180 | 200 | 200 | 220 | 260 | 260 | |||||||||
| 最大頂出推力 Ejector Force | Kn | 125 | 125 | 152 | 152 | 182 | 182 | 182 | 232 | 232 | |||||||||
| 電控部份 | |||||||||||||||||||
| 总電机功率(变量泵/伺服) Pump Motor Power (V Pump/Servo) | Kw | 30 | 37 | 30 | 37 | 37 | 46 | 37 | 46 | 48.5 | 55 | 52 | 65 | 55.5 | 65 | 55.5 | 65 | 59 | 75 |
| 電熱功率 Heater Power | Kw | 18 | 18 | 20.2 | 24 | 32 | 36 | 40 | 40 | 45 | |||||||||
| 温度控制區 No.of Heater Control Zone | zone | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | |||||||||
| 系統壓力 System Pressure | Mpa | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | |||||||||
| 其他 | |||||||||||||||||||
| 油箱容量 Oil Tank Capacity | L | 400 | 400 | 450 | 600 | 650 | 800 | 900 | 900 | 1000 | |||||||||
| 重量(约) Machine Weight | kg | 7700 | 7700 | 9100 | 13500 | 14300 | 16100 | 22200 | 26300 | 28800 | |||||||||
| 外型尺寸 Machine Dimension (LxWxH) | M | 5.5 X 1.6 X 2.2 | 6.1 X 1.6 X 2.2 | 6.6 X 1.6 X 2.2 | 7.4 X 1.7 X 2.2 | 8.2 X 1.8 X 2.3 | 8.6 X 1.9 X 2.2 | 9.6 X 2.1 X 2.4 | 9.9 X 2.2 X 2.4 | 10.3 X 2.2 X 2.4 | |||||||||
Detail Pictures
