| Place of Origin: | China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE |
| Model Number: | OUCO- 170/470G |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | shipping container |
| Delivery Time: | 35 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 2500 Set/Sets per Year |
| Plastic Type: | Thermoplastic | Screw L/D Ratio: | 22 |
|---|---|---|---|
| Injection Weight: | 60g | Key Selling Points: | High Productivity |
| Core Components: | Gearbox | Fuel Tank Capacity: | 320 |
| High Light: | ABS plastic molding machine,1.4*1.8m plastic molding machine,60g Intelligent Optimized Injection Machine |
||
Efficient Injection Structure, Screw load more uniformly, Screw load more uniformly, Better plasticizing capacity, Low energy cost, Injection stable and more efficient.
Product Parameters
|
Product name |
Injection molding machine |
|
Number of heating sections |
4 |
|
Barrel heating power |
4.7 |
|
Fuel tank capacity |
320 |
|
Machine size |
4.7*1.4*1.8 m |
|
Plastic Processed |
PP,ABS,PE,HDPE/PP |
|
Condition |
New |
|
Style |
Horizontal |
|
Plastic Type |
Thermoplastic |
|
Clamping Force (kN) |
1100 KN |
|
Distance between Tie Bars |
470*410 |
|
Machine Type |
Hydraulic |
|
Type |
Tube Head Injection |
|
Automatic |
YES |
|
Warranty |
1 Year |
|
After-sales Service Provided |
Video technical support |
|
After-sales Service Provided |
Field installation, commissioning and training |
|
After-sales Service Provided |
Field maintenance and repair service |
|
After-sales Service Provided |
Online support |
|
Key Selling Points |
High Productivity |
|
Applicable Industries |
Manufacturing Plant |
|
After Warranty Service |
Video technical support |
|
Machinery Test Report |
Provided |
|
Video outgoing-inspection |
Provided |
|
Warranty of core components |
1 Year |
|
Core Components |
Bearing |
|
Distance between Tie Bars(Height)(mm) |
470 |
|
Distance between Tie Bars(Width)(mm) |
410 |
|
Plasticizing Capacity(g/s) |
35 |
|
Mold Height(mm) |
180 - 520 mm |
|
Ejector Stroke(mm) |
140 |
|
Ejector Force(kN) |
67 kN |
|
Theoretical Shot Volume(cm³) |
366 cm³ |
|
Injection Rate (g/s) |
389 g/s |
|
Injection Weight (g) |
60 |
|
Screw diameter (mm) |
35 |
|
Screw L/D Ratio |
22 |
|
Weight (KG) |
5000 |
|
Open Stroke(mm) |
430 |
|
Model Number |
LS170/470G |
|
Power (kW) |
55 kW |
Product Features
Models
|
clamping force |
1700 |
|||||
|
locking force |
1870 |
|||||
|
max.mould opening stroke |
430 |
|||||
|
min.mould height |
180 |
|||||
|
max.mould height |
520 |
|||||
|
max.daylight |
950 |
|||||
|
mould platen(h*v) |
715*655 |
|||||
|
ejction stroke |
140 |
|||||
|
ejction force |
67 |
|||||
|
injection unit |
340 |
600 |
||||
|
screw diameter |
30 |
35 |
40 |
40 |
45 |
50 |
|
screw geometry |
standard |
|||||
|
l/d ratio |
22 |
22 |
22 |
22 |
22 |
22 |
|
max.shot weight(ps) |
122 |
167 |
217 |
263 |
366 |
452 |
|
max.screw stroke |
190 |
190 |
190 |
230 |
230 |
230 |
|
max.nozzle dipping depth(svo) |
|
50 |
|
|
50 |
|
|
nozzle sealing force |
|
80 |
|
|
80 |
|
|
number of heating zones |
|
5 |
|
|
5 |
|
|
hopper capacity |
|
35 |
|
|
35 |
|
|
>capacity with electr drive |
52 |
55 |
57 |
67 |
70 |
73 |
|
net weight(without oil) |
5000 |
5400 |
||||
