| Place of Origin: | China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE |
| Model Number: | OUCO- 170G |
| Minimum Order Quantity: | 1 |
| Delivery Time: | 35 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2500 Set/Sets per Year |
| Product: | LS170G High Speed Small Servo Plastic Injection Molding Machine | Plastic Type: | Thermoplastic |
|---|---|---|---|
| Automatic: | Yes | Language: | Language Customized |
| Key Selling Points: | High Productivity | Core Components: | Gearbox |
| Fuel Tank Capacity: | 320 | Packaging: | Shipping Container |
| High Light: | LS170G Automatic Injection Moulding Machine,CE Automatic Injection Moulding Machine,HDPE Servo Injection Molding Machine |
||
OUCO servo plastic injection molding machine has higher efficiency and reliability. The support of the shooting table adopts high-precision blanket rail, with low friction coefficient, injection and low and uni-form plasticizing resistance, faster injection speed, suitable for high-speed precision injection forming.
Basic Information
Price: As show, large quantity discount, please consult the store for details
Plastic Processed: PP
Plastic Processed: PC
Plastic Processed: HDPE/PP
Plastic Processed: ABS/PP
Plastic Processed: PE/PP
Condition: New
Machine Type: Hydraulic
Type: Injection Molding
Warranty:1 Year
After-sales Service Provided: Video technical support
After-sales Service Provided: Field installation, commissioning and training
After-sales Service Provided: Field maintenance and repair service
After-sales Service Provided: Online support
Key Selling Points: High Productivity
Applicable Industries: Manufacturing Plant
After Warranty Service: Video technical support
After Warranty Service: Online support
After Warranty Service: Field maintenance and repair service
Product Parements
Style:Horizontal
Distance between Tie Bars(Width)(mm):470mm
Distance between Tie Bars(Height)(mm):410mm
Mold Height(mm):180 - 520 mm
Ejector Stroke(mm):140
Ejector Force(kN):67
Theoretical Shot Volume(cm³):183
Injection Rate (g/s):404
Injection Weight (g):167
Screw diameter (mm):35
Screw L/D Ratio:22
Distance between Tie Bars:470*410
Weight (KG):5000
Open Stroke(mm):430
Model Number:LS170/470G
Brand Name:LISONG
Certification:As Required
Power (kW):55
Marketing Type:New Product 2021
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Warranty of core components:1 Year
Model
|
clamping unit
|
LS170/470 G
|
|||||
|
clamping force
|
1700
|
|||||
|
locking force
|
1870
|
|||||
|
max.mould opening stroke
|
430
|
|||||
|
min.mould height
|
180
|
|||||
|
max.mould height
|
520
|
|||||
|
max.daylight
|
950
|
|||||
|
mould platen(h*v)
|
715*655
|
|||||
|
ejction stroke
|
140
|
|||||
|
ejction force
|
67
|
|||||
|
injection unit
|
340
|
600
|
||||
|
screw diameter
|
30
|
35
|
40
|
40
|
45
|
50
|
|
screw geometry
|
standard标准
|
|||||
|
l/d ratio
|
22
|
22
|
22
|
22
|
22
|
22
|
|
max.shot weight(ps)
|
122
|
167
|
217
|
263
|
333
|
411
|
|
max.screw stroke
|
190
|
190
|
190
|
190
|
190
|
190
|
|
max.nozzle dipping depth(svo)
|
|
50
|
|
|
50
|
|
|
nozzle sealing force
|
|
80
|
|
|
80
|
|
|
number of heating zones
|
|
5
|
|
|
5
|
|
|
hopper capacity
|
|
35
|
|
|
35
|
|
|
>capacity with electr drive
|
52
|
55
|
57
|
67
|
70
|
73
|
|
net weight(without oil)
|
5000
|
5400
|
||||
