| Place of Origin: | China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE |
| Model Number: | OUCO-HS-530T |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | shipping container |
| Delivery Time: | 35 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2500 Set/Sets per Year |
| Product: | Small Footprint Plastic Fully Automatic Injection Mold Machine HS Series | Power: | 50.7 KW |
|---|---|---|---|
| Screw Diameter: | 180 Mm | Open Stroke: | 1850 Mm |
| Applicable Industries: | Food & Beverage Factory, Home Use | Core Components: | Pump |
| Style: | Style | Condition: | New |
| Automatic: | Yes | Certification: | ISO9001:2008,CE,TUV |
| High Light: | TUV Footprint small injection molding machine,180mm small injection molding machine,HS Series injection mold machine |
||
Our HS series enables you to increase your production efficiency to the maximum. Leading technology and performance, central locking toggle .Smallest footprint, most energy-efficient drive technology large option portfolio, maximum flexibility and uptime. All at an attractive package price.
| CWI-110GB CWI-150GB | |||||||||||
| 机型 | CWI-110GB | CWI-150GB | |||||||||
| 合模装置 | 锁模力 Kn | clamping force (kN) | 1100 | 1500 | |||||||
| 拉杆间距 mm | Tie bar distance W×L (mm) | 420×420 | 470×470 | ||||||||
| 开模最大开距 mm | Clamping Stroke | 400 | 450 | ||||||||
| 最大模厚 mm | Max. mold thickness (mm) | 450 | 520 | ||||||||
| 最小模厚 mm | Min. mold thickness(mm) | 150 | 170 | ||||||||
| 模板尺寸 mm | Platen Dimensions W×L (mm) | 605×605 | 680×680 | ||||||||
| 顶出长度 mm | Ejector Stroke | 110 | 140 | ||||||||
| 顶出力 Kn | Ejector Force | 38 | 53 | ||||||||
| 顶针数 | Ejector Quantily | 5 | 5 | ||||||||
| 310D | 420D | 420D | 650D | ||||||||
| 注射装置 | 螺杆直径 mm | Screw Diameter(mm) | 28 | 32 | 35 | 35 | 40 | 35 | 40 | 40 | 45 |
| 螺杆长径比 | Screw L/D ratio | 23.4 | 23 | 21 | 24 | 21 | 24 | 21 | 23.6 | 21 | |
| 理论射胶容积 cm3 | Theoretical injection volume (cm3) | 89 | 117 | 140 | 163 | 214 | 163 | 214 | 251 | 318 | |
| 注射重量 (PS)g | Shot Weight | 81 | 108 | 129 | 150 | 196 | 150 | 196 | 231 | 292 | |
| 注塑压力 Mpa | Injection Pressure(MPa) | 306 | 234 | 204 | 256 | 196 | 256 | 196 | 240 | 190 | |
| 注射速度 mm/s | Injection Speed | 129 | 101 | 126 | 100 | ||||||
| 注塑速率 cm3/s | Injection Rate (cm3/s) | 76 | 99 | 119 | 93 | 121 | 116 | 151 | 138 | 175 | |
| 螺杆最大转速 rpm | Screw Speed | 330 | 250 | 300 | 220 | ||||||
| 其他 | 油泵电机功率 Kw | Motor Power | 16 | 20 | |||||||
| 油泵排量 L/min | 88 | 110 | |||||||||
| 电热功率 Kw | Heater Power | 7.11 | 8.91 | 8.91 | 10.9 | ||||||
| 机器净重 ton | Machine Weight (kg) | 4.2 | 5.2 | ||||||||
| 机器尺寸(长×宽×高) mm | Machine size L×W×H (mm) | 4255×1430×1690 | 5095×1500×1745 | ||||||||
Main Features
Due to the high wastage of clamping force in conventional constructions, efficiency is only 80 - 85% and there is significant distortion of the moving platen, resulting in flying edges and wasted material and labour in trimming the flying edges.
OUCO has designed a central clamping structure that ensures 100% clamping force is used.
Not only does it reduce the possibility of flashing, but it also saves flash trim work.
Saves 2-5% of material while providing good protection for the mould, platens and tie bars.
10-20% longer opening stroke.
